ShoreMaster Hydraulic Lifts: Pure Power. Pure Peace of Mind.

Your time on the water is too valuable to waste on handwheels, cables, or constant adjustments. With ShoreMaster’s true hydraulic boat lifts, every launch is effortless, giving you more time for sunrise cruises, tubing runs, or evenings dockside with family and friends.

Engineered for uncompromising reliability and tested well beyond rated capacities, our hydraulic lifts deliver quiet, push-button performance season after season—so your boat is always ready when you are.

Find a Dealer

Experience the power, reliability, and peace of mind only ShoreMaster Hydraulics deliver.

From shallow sandy bays to deeper fluctuating lakes, ShoreMaster’s hydraulic lifts adapt seamlessly to your shoreline.

Your time on the water is too precious to spend wrestling with handwheels, cables, or complicated upkeep. With ShoreMaster’s true hydraulic boat lifts, getting out on the lake becomes effortless—so you can focus on sunrise cruises, afternoon floats, and evenings dockside with friends.

  • Ideal for water depths from 3’ to 7’ (16” + boat draft minimum)

  • Performs flawlessly in soft, firm, or semi-firm bottoms

  • True cantilever hydraulic design excels where cable lifts struggle

Picture this: your boat, resting securely above the chop, ready to launch at a touch of your remote—no ropes, no cranking, no second guessing.

GET A QUOTE FROM YOUR LOCAL DEALER

The ShoreMaster Difference

Engineered for unmatched strength and tested beyond capacity, our lifts deliver quiet, push-button performance season after season. Your boat stays protected and ready, every time you are.

Unmatched Durability

True Capacity

Many brands hedge on capacity—ours are guaranteed to lift 100% of their rated weight, backed by over-engineered, dime-welded frames that stand up to years of waves, wakes, and weather.

Minimal Maintenance

True Hydraulic Design

No cables, no pulleys, no constant adjustments. Our sealed hydraulic system minimizes maintenance, offers precise lifting, and lays flat in water as shallow as 16" + boat draft—perfect for varying lake levels.

Effortless Operation

True Performance

Lift your boat at ~1 inch per second with smooth, whisper-quiet precision. Remote operation is standard, so you’re on the water faster with zero manual effort.

PRODUCT HIGHLIGHTS & TECH SPECS

Dime-Welded Construction: Stronger than bolt-together frames, with no bolts to loosen or rust.

Quiet, Smooth Operation: Pressure-balanced, bi-rotational pump delivers efficient, silent lifting.

Remote Control Standard: Every lift includes a 40’ remote and Bluetooth LiftTech app.

48” or 60” Lift Travel: Options to match your shoreline and water fluctuations.

Wide Capacity Range: Available from 6,000 to 12,500 lbs, including TruLift models (8,000–12,500).

Low Water Ready: Lay-flat hydraulic design works in just 16” + boat draft.

Rails & Bunks: Configurable for pontoons, sailboats, or V-hulls (6,000 lb models only)

Warranty: 15-year structural warranty on frames

WHERE THESE LIFTS EXCEL

From shallow sandy bays to deeper fluctuating lakes, ShoreMaster’s hydraulic lifts adapt seamlessly to your shoreline.

  • Ideal for water depths from 3’ to 7’ (16” + boat draft minimum)

  • Works equally well in soft or firm bottom conditions

  • True cantilever hydraulic design excels in fluctuating water or sites where traditional vertical cable lifts struggle

  • Perfect for protecting V-hulls, pontoons, tritoons, and even sailboats with specialty bunks & rails

Picture this: your boat, resting securely above the chop, ready to launch at a touch of your remote—no wrestling ropes, no second guessing.

Find a Dealer

GALLERY

SPECIFICATIONS

Model
Capacity
Inside Width
Lift Travel
Std. Leg Length
Overall Width
Overall Length
Min. Water Depth*
Canopy Length

600948 HYD

6,000 lbs

108”

48”

36”

120”

124”

26"+

21-29’

601060 HYD

6,000 lbs

120"

60”

36”

132”

124”

26"+

23-33’

801048 TRU

8,000 lbs

120"

48”

36”

134"

194"

16"+

23-33’

801060 TRU

8,000 lbs

120"

60”

36”

134"

194"

16"+

23-33’

801148 TRU

8,000 lbs

132”

48”

36”

149”

194"

16"+

27-35’

801160 TRU

8,000 lbs

132”

60”

36”

149”

194"

16"+

27-35’

101148 TRU

10,000 lbs

132”

48”

36”

149”

206”

16"+

27-35’

101160 TRU

10,000 lbs

132”

60”

36”

149”

206”

16"+

27-35’

121148 TRU

12,000 lbs

132”

48”

36”

149”

233"

16"+

27-35’

121160 TRU

12,000 lbs

132”

60”

36”

149”

233"

16"+

27-35’

*Minimum water depth required is listed value PLUS boat hull

SHOREMASTER CANOPY SYSTEMS

The ShoreMaster canopy system provides industry-leading protection from the elements as well as easy installation and ownership, making it the ideal choice for watercraft owners. Available in two frame styles, three fabric options and numerous colors you canopy system will be more than just incredibly functional, it’ll be a reflection of your style as well.

EXPLORE OUR CANOPY SYSTEMS

FAQs for Infinity Hydraulic Lifts:

What’s the advantage over a cable lift?

Hydraulic lifts eliminate exposed cables and pulleys that fray, stretch, or corrode. With fewer moving parts, they need less maintenance and deliver smooth, direct lifting at the push of a button.

What kind of power do I need?

A 12V Group 27+ marine deep cycle battery is all you need. Pair with a solar kit for maintenance-free charging.

How fast is the lift?

About 1 inch per second—meaning your boat is water-ready in around a minute.

Can it handle fluctuating water levels?

Yes. With 48” or 60” lift travel and a lay-flat resting height, ShoreMaster hydraulics handle seasonal changes with ease.

Do you offer installation support?

Yes. Our nationwide dealer network provides expert installation, service, and ongoing support near you.
