Effortless Lifting, Maximum Protection
Engineered for shallow to moderate depths, this lift delivers powerful hydraulic performance, low-maintenance design, and effortless operation to protect your boat season after season.
| Ideal for 3–9 Ft Water DepthsPerforms flawlessly in soft, firm, or semi-firm bottoms and shallow-water conditions. |
| Hydraulic Power = Fewer Parts, Less MaintenanceJust smooth hydraulic lifting that reduces wear and long-term upkeep. |
| Flexible PlacementBuilt to handle a wide variety of lakefront setups, even where traditional lifts struggle. |
| Quick, Push-Button OperationLaunch or lift in seconds with remote or app controls. No handwheels, no cranking, no hassle. |
Built For The Way You Live on the Water
Your best lake days aren’t planned — they just happen. Evening cruises, last-minute tubing runs, and impromptu gatherings shouldn’t be delayed by outdated, hard-to-use lifts.
ShoreMaster’s Vertical Hydraulic Boat Lifts give you smooth, push-button control so you can raise or lower your boat in seconds. No heavy cranks. No waiting. Just reliable performance every time.
Built with dime-welded aluminum frames, corrosion-resistant hydraulic housings, and intuitive remote + Bluetooth app controls, this is lake life made effortless, dependable, and safe.
CONSTRUCTION DETAILS
Frame Construction
Precision dime-welded, marine-grade aluminum for maximum strength and long-term durability
Heavy-duty connection points with reinforced corners built to handle today’s heaviest boats
Operation
Clean, powerful hydraulic cylinders deliver smooth, push-button lifting and lowering
Corrosion-resistant hydraulic housing protects pumps and components from the elements
Remote + Bluetooth app control for effortless operation from dock or shoreline
Built-in safety stops prevent over-lifting or over-lowering, protecting both boat and lift
Design Features
66"–70" vertical rack travel adapts easily to fluctuating water levels
Configurable bunks for pontoons, tritoons, and V-hulls
Reinforced aluminum cross-members for stability under heavy loads
Wide stance and solid footing provide dependable performance in 3–9 ft depths
Low Maintenance
Welded seams reduce the need for bolt checks and seasonal adjustments
All-aluminum and stainless-steel construction = corrosion-free, decades of use
Sealed hydraulics and greaseable fittings for smooth, worry-free operation
PRODUCT HIGHLIGHTS
Welded Aluminum Frame – Dime-welded construction for unmatched strength and long-term durability.
66"–68" Rack Travel – Smooth vertical travel that easily handles fluctuating water levels.
4,000–15,000 lb Capacities – Ready for today’s heaviest pontoons, tritoons, and luxury boats.
Remote + Bluetooth Operation – Standard 40' range with remote; LiftTech app extends up to 100'+.
Corrosion-Resistant Hydraulic Housing – Protects vital components from wear and weather.
Built-In Safety Stops – Prevents cable fatigue and damage from overloading.
Custom Fit Options – Configurable bunks and rails for pontoons, tritoons, V-hulls, and sailboats.
Greaseable Pulleys + Long-Lasting Cables – Smooth operation with reduced maintenance.
Fast, 8-Piece Assembly – The easiest seasonal install and take-down in the industry.
Best-in-Class Warranty – 15 years on the frame, 12 years on cables.
SPECIFICATIONS
Model | Capacity | Inside Width | Lift Travel | Std. Leg Length | Overall Width | Overall Length | Min. Water Depth. | Canopy Length |
4010 VHL | 4,000 LBS | 120" | 66" | 36" | 132" | 127" | 5.75" + draft of the boat | 23'-33' |
5010 VHL | 5,000 LBS | 120" | 66" | 36" | 132" | 127" | 5.75" + draft of the boat | 23'-33' |
5510 VHL PTN | 5,500 LBS | 120" | 66" | 36" | 132" | 127" | 5.75" + draft of the boat | 23'-33' |
6010 VHL | 6,000 LBS | 120" | 66" | 36" | 132" | 127" | 5.75" + draft of the boat | 23'-33' |
7010 VHL | 7,000 LBS | 120" | 68" | 36" | 136" | 166" | 10" + draft of the boat | 23'-33' |
8010 VHL | 8,000 LBS | 120" | 68" | 36" | 136" | 166" | 10" + draft of the boat | 23'-33' |
8011 VHL | 8,000 LBS | 120" | 68" | 36" | 148" | 166" | 9.5" + draft of the boat | 23'-33' |
10011 VHL | 10,000 LBS | 132" | 70" | 36" | 148" | 166" | 11" + draft of the boat | 23'-33' |
12011 VHL | 12,000 LBS | 132" | 70" | 36" | 148" | 166" | 11" + draft of the boat | 23'-33' |
15011 VHL | 15,000 LBS | 132" | 70" | 36" | 148" | 238" | 11" + draft of the boat | 23'-33' |
FAQs for Infinity Vertical Hydraulic Boat Lifts:
What water depths work best for a hydraulic lift?
Ideal for 3–7 ft depths. Adjustable rack travel up to 68" means easy handling of fluctuating levels.
Can I use this for a tritoon or sailboat?
Yes — custom bunks and adjustable configurations make this lift perfect for pontoons, tritoons, V-hulls, and sailboats.
How far does the remote work?
About 40 ft with the standard remote, up to 100+ ft with the Bluetooth app, depending on your site.
Do I need special power?
Just a standard 12V group 27 marine battery (minimum 500 CCA). Ask your dealer for solar options to keep it charged.
Is it really lower maintenance?
Absolutely. Fewer moving parts, greaseable pulleys, and sealed hydraulics mean less wear and easier upkeep than traditional cable lifts.
Is there a limit switch?
No. When the cylinder is fully retracted, the lift stops lifting and the pump tone changes. When fully extended, it stops lowering and tone changes.
What is the remote range?
LiftTech specs: 40 ft with remote, 80 ft with app. In clear line of sight, often 80+ ft with remote and 100+ ft with the app.
Can the hydraulic pump be mounted on the dock?
Yes — hydraulic hose extensions and dock-mounting options are available.
Is the battery provided?
No. Dealers/customers must provide a battery. We recommend a 12V group 27 marine deep cycle battery with minimum 500 CCA or 160 amp hours reserve capacity.
